AMBER Stainless Steel Soundproofing Airtight Sliding Door for Hospital

AMBER Stainless Steel Soundproofing Airtight Sliding Door for Hospital

Place of Origin:

China

Marca:

Amber

Certificazione:

CE, ISO, GMP

Model Number:

Am-AHD018

contattici

Richieda una citazione
Dettagli del prodotto
Warranty:
1 year
Surface treatment:
Indoor elctrostatic spraying/Outdoor fluorocarbon coating/SUS304
Guide Rail:
aluminium alloy or stainless steel
Opening Method:
Hand/foot/infrared
Safety Features:
Emergency stop button, safety sensors, and backup battery
Certifications:
CE, ISO 9001, GMP
Steel Plate Thickness:
1.0mm or Customized
Closing Speed:
250-450mm/s(adjustable)
Opening Speed:
250-450mm/s(adjustable)
Power supply:
AC220V 50-60HZ
Door window:
400*400/400*600/600*600
Standard size:
1200*2100 1500*2100 1800*2100
Termini di trasporto & di pagamento
Minimum Order Quantity
1 set
Packaging Details
plywood case
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
1000 set per month
Descrizione di prodotto



Soundproofing Airtight Sliding Door is made of stainless steel, which has sound insulation and excellent airtightness. It can effectively block air convection and noise interference, ensure the cleanliness and quietness of the indoor environment, and is often used in operating rooms, ICUs, laboratories and other places.



What is Airtight Sliding Door?



Airtight Sliding Door refers to a special door that can fit tightly with the door frame after the door is closed, forming a good sealing effect, and preventing air, dust, bacteria, etc. from entering or leaking from the door gap. It is usually equipped with the Airtight Automatic Door system to achieve automatic switching and inductive operation to avoid contact and cross infection.



Application scenarios of Airtight Automatic Door



  • Biopharmaceutical workshop: effectively isolate different production areas to prevent cross contamination.



  • Food processing clean workshop: ensure that the production environment meets the standards.



  • Electronic dust-free workshop: maintain constant temperature and humidity to prevent the invasion of dust particles.



  • Experimental animal center: ensure the biosafety level of the laboratory environment.



  • Radiology department, nuclear medicine room: cooperate with lead plate protection design to block radiation leakage.



These application scenarios have strict requirements on air tightness and smooth and silent opening and closing.



Product features of Hospital Automatic Doors



  • 304 or 316 medical grade stainless steel



  • Dual protection of air tightness and sound insulation



  • Intelligent automatic sensing systems such as foot sensing, hand sensing, radar sensing, etc.



  • Smooth and low-noise operation



  • Customized size and functional configuration



Why choose AMBER?



As a professional Modular Operating Theater solution provider, Amber has more than 17 years of rich experience in the clean industry. AMBER not only provides high-quality clean door products, but also can be equipped with a full set of medical clean equipment such as surgical lights, operating tables, FFU fan filter units, air showers, etc., to provide one-stop clean space customization services for hospitals and pharmaceutical customers.



Specifications



Model 1200*2100 1500*2100 1800*2100 2000*2100
Door size mm(W*H)
1200*2100 1500*2100 1800*2100 2000*2100
Door hole size mm (W*H)
1100*2050 1400*2050 1700*2050 1900*2050
Motor slide rails mm (Length) 2600 3200 3800 4200
Motor slide rails mm (Heigth) 2270 2270 2270 2270
Door windows Window with arc
Door fillings
Fire-resistant aluminum honeycomb
Door surface treatment
Indoor surface electrostatic spraying/outdoor fluorocarbon spraying /304 stainless steel
Opening method
Hand/foot/infrared/microwave induction
Operating speed of
open and closed door
250-550mm/s(Adjustable)
Power voltage
AC220V 50-60HZ



FAQ



Q1: What sizes and opening methods are available for AMBER Stainless Steel Airtight Sliding Doors?

A: We provide standard sizes (1200×2100mm) and support customized services, which can be customized according to the door opening sizes and wall structures of different operating rooms.

The opening methods include radar sensing, hand sensing, foot switch, access control linkage, etc., to meet the automatic door control needs of different hospitals.



Q2: In addition to hospitals, what other places can this airtight automatic door be used for?

A: In addition to hospital operating rooms and ICUs, Airtight Automatic Door is also widely used in biopharmaceutical workshops, food clean workshops, electronic dust-free workshops, experimental animal centers, and radiology shielding door systems, etc. It is applicable to all clean places that require airtightness, sound insulation, and barrier-free operation.
